Compact rollable‑ribbon pigtails in G.657.A1 single‑mode — splice 12 fibres in one hit and slash tray real‑estate.
- Flexible‑ribbon geometry collapses for easy routing then lays flat for mass‑fusion
- Splice 12 at once, up to 8× faster than single fibres
- Factory‑polished LC, SC, and MPO terminations
- UPC and APC finishes for performance tuning
- Factory tested for insertion and return loss on every core
Engineered to Outperform
Delivered with Certainty
Procurement Made Simple
Rapid Deployment Ready
Ready To Scale
Compliance Assured
ScaleFibre Flexible Ribbon Optical Pigtails combine the high‑count efficiency of ribbon with the handling ease of loose fibres. The rollable design collapses into a tight bundle for congestion‑free routing, then fans out into a flat ribbon for a single 12‑fibre mass‑fusion splice.
Each assembly is factory‑terminated and 100 % optically tested, guaranteeing low insertion loss and high return loss. Choose LC, SC or MPO connectors in UPC or APC polish to match your patching architecture. Ideal for hyperscale data centres, 5G front‑haul, and high‑density ODF builds where every millimetre of tray space counts.
| Technical Specifications | |
| Ribbon Type | Rollable / flexible ribbon, 250 µm fibres |
| Fibre Counts | 12F |
| Fibre Grades | Single‑mode G.657.A1 |
| Connector Types | LC, SC, MPO (Female or Male) |
| Polish Options | UPC or APC |
| Configuration | Unterminated end presented as mass‑fusion ready ribbon |
| Standard Lengths | 2 metres |
| Insertion Loss | ≤ 0.12 dB (Mean), ≤ 0.25 dB (Max) - IEC Grade B |
| Return Loss | ≥ 55 dB (UPC), ≥ 65 dB (APC) - Grade 1 |
| Operating Temperature | –20 °C to +70 °C |
| Relevant Standards | IEC 61754 / 61755, TIA/EIA‑568, RoHS, REACH |
| Standard 250µm Flexible Ribbon Pigtails | |
| PT-S7-FR-LC-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, LC/UPC, 2 metres, 1PK, Coloured |
| PT-S7-FR-LCA-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, LC/APC, 2 metres, 1PK, Coloured |
| PT-S7-FR-SC-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, SC/UPC, 2 metres, 1PK, Coloured |
| PT-S7-FR-SCA-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, SC/APC, 2 metres, 1PK, Coloured |
| MPO 3mm Cord 250µm Flexible Ribbon Pigtails | |
| PT-S7-FR3-MPOF-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, 3mm Cord, MPO(12F)-Female, 2 metres, 1PK, Coloured |
| PT-S7-FR3-MPOM-2M-1 | Pigtail, Single Mode (G.657.A1), 12F 250µm Flexible Ribbon, 3mm Cord, MPO(12F)-Male, 2 metres, 1PK, Coloured |
